SLBC-120 Plastic Injection Molding Machine Fully Automatic HDPE Bottle Extrusion Blow Molding Machines
SLBC-120 Plastic Injection Molding Machine Fully Automatic HDPE Bottle Extrusion Blow Molding Machines
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Unit price
per
Tax included.
Couldn't load pickup availability
Products Description
Extrusion blow - molding machines are widely used to produce various hollow plastic containers for food, toys, beverages, pharmaceuticals, chemical products, detergents, water bottles, baby bottles, oil bottles, plastic balls, cosmetic bottles, lubricant bottles, and plastic containers. These machines have the advantages of low investment, high efficiency, fast and safe operation, easy troubleshooting, and maintenance.
One-stop service
We focus on supporting your business through comprehensive market research, product selection, and optimizing factory layout. Our goal is to maximize your investment by helping you obtain a considerable return. From the initial project consultation to capacity planning and continuous after - sales support, we provide a complete service package to meet your needs.
Product Paramenters
|
SLBC-120
|
||
|
Specifications
|
||
|
Material
|
|
PE, PP, EVA, ABS,PS...
|
|
Max container capacity
|
L
|
60
|
|
Output(dry cycle)
|
pc/hr
|
300
|
|
Machine Dimension(LxWxH)
|
M
|
7500*4200*6200
|
|
Total weight
|
Ton
|
22T
|
|
Clamping Unit
|
||
|
Clamping force
|
Kn
|
800
|
|
Platen opening stroke
|
mm
|
600 ---1400
|
|
platen size(WxH)
|
mm
|
1400*1600
|
|
Max mould size(WxH)
|
mm
|
1200*1900
|
|
Mold thickness
|
mm
|
610---880
|
|
Extruder unit
|
||
|
Screw diameter
|
mm
|
90
|
|
Screw L/D ratio
|
L/D
|
25
|
|
Melting capacity
|
Kg/Hr
|
140
|
|
Number of heating zone
|
Kw
|
20
|
|
Extrudedr heating power
|
Zone
|
5
|
|
Extruder driving power
|
Kw
|
45
|
|
Die head
|
||
|
Number of hearting zone
|
Zone
|
4
|
|
Power of die heating
|
Kw
|
18
|
|
Max die-pin diameter
|
mm
|
400
|
|
Power
|
||
|
Wax drive
|
Kw
|
57
|
|
Total power
|
Kw
|
105
|
|
Fan power for screw
|
Kw
|
4
|
|
Air pressure
|
mpa
|
0.8
|
|
Air consumption
|
m³/min
|
0.8
|
|
Average energy consumption
|
Kw
|
38
|
|
Accumulator capacity
|
L
|
8
|
